Cisco Updated 350-701 Exam Questions and Answers by merryn

Explanation

Domain name system (DNS) is the protocol that translates human-friendly URLs, such as securitytut.com, into IP addresses, such as 183.33.24.13. Because DNS messages are only used as the beginning of each communication and they are not intended for data transfer, many organizations do not monitor their DNS traffic for malicious activity. As a result, DNS-based attacks can be effective if launched against their networks. DNS tunneling is one such attack.

An example of DNS Tunneling is shown below:

The attacker incorporates one of many open-source DNS tunneling kits into an authoritative DNSnameserver (NS) and malicious payload.2. An IP address (e.g. 1.2.3.4) is allocated from the attacker’s infrastructure and a domain name (e.g. attackerdomain.com) is registered or reused. The registrar informs the top-level domain (.com) nameservers to refer requests for attackerdomain.com to ns.attackerdomain.com, which has a DNS record mapped to 1.2.3.43. The attacker compromises a system with the malicious payload. Once the desired data is obtained, the payload encodes the data as a series of 32 characters (0-9, A-Z) broken into short strings (3KJ242AIE9, P028X977W,…).4. The payload initiates thousands of unique DNS record requests to the attacker’s domain with each string as

Joining Cisco WSAs to an appliance group simplifies the task of patching multiple appliances. An appliance group is a collection of WSAs that share the same configuration settings and software versions. Administrators can use appliance groups to apply configuration changes and software updates to multiple WSAs at once, instead of performing these tasks individually for each appliance12. This reduces the administrative overhead and ensures consistency across the WSAs. References:

Appliance groups, section “Appliance Groups”.

What is the purpose of joining Cisco WSAs to an appliance group?

To collect full metadata information about the traffic going through their AWS cloud services, the organization needs to send VPC Flow Logs to Cisco Stealthwatch Cloud and configure Cisco Stealthwatch Cloud to ingest AWS information. VPC Flow Logs is a feature that enables the organization to capture information about the IP traffic going to and from network interfaces in their VPC. Flow log data can be published to Amazon CloudWatch Logs, Amazon S3, or Amazon Kinesis Data Firehose1. Cisco Stealthwatch Cloud is a SaaS-based network and cloud security solution that provides behavioral analytics across the network to help the organization improve threat detection and achieve a stronger security posture2. By sending VPC Flow Logs to Cisco Stealthwatch Cloud, the organization can leverage the rich network flow metadata to perform various types of flow analysis, such as troubleshooting connectivity issues, monitoring the traffic patterns, detecting anomalous or malicious activity, and verifying compliance3. To send VPC Flow Logs to Cisco Stealthwatch Cloud, the organization needs to create a flow log for their VPC, subnet, or network interface, and specify Cisco Stealthwatch Cloud as the destination4. To configure Cisco Stealthwatch Cloud to ingest AWS information, the organization needs to add their AWS account as a data source in the Cisco Stealthwatch Cloud portal, and grant the necessary permissions for Cisco Stealthwatch Cloud to access their VPC Flow Logs5. By doing so, the organization can view and analyze the flow log data in the Cisco Stealthwatch Cloud dashboard, and receive valuable security alerts and insights based on the network behavior6.

References := 1: Logging IP traffic using VPC Flow Logs - Amazon Virtual Private Cloud 2: Cisco Secure Cloud Analytics (Stealthwatch Cloud) - Cisco 3: Cisco Secure Cloud Analytics - AWS VPC Flow Logs: A New Tool for Your … 4: Publish flow logs to Cisco Stealthwatch Cloud - Amazon Virtual Private Cloud 5: AWS Data Source Setup - Cisco Stealthwatch Cloud 6: AWS Workload Protection - Cisco Stealthwatch Cloud

MAB is a fallback mechanism for IEEE 802.1X that allows network access based on the MAC address of the endpoint. However, MAB does not prevent MAC address spoofing, which is a technique used by attackers to impersonate authorized devices and bypass authentication. To mitigate this risk, two catalyst switch security features can be used in conjunction with MAB: 802.1AE MacSec and port security.

802.1AE MacSec is a standard that provides encryption and integrity protection for data frames between two MACsec-capable devices. MacSec also uses a secure key exchange protocol called MKA (MACsec Key Agreement) to establish and maintain cryptographic keys between the peers. By enabling MacSec on the switch ports, the switch can verify the identity and authenticity of the endpoints and prevent unauthorized access or tampering with the data frames.

Port security is a feature that allows the switch to limit the number and type of MAC addresses that can access a port. Port security can be configured to allow only a specific MAC address or a maximum number of MAC addresses per port. Port security can also be configured to take an action when a violation occurs, such as shutting down the port, sending a trap, or dropping packets. By enabling port security on the switch ports, the switch can prevent multiple devices from accessing the same port or deny access to devices with spoofed MAC addresses.
