Cisco Updated 350-701 Exam Questions and Answers by aj

To route inbound email to Cisco Cloud Email Security (CES), the engineer must modify the MX record of the domain to point to the CES hostname or IP address. The MX record is a DNS record that specifies the mail server responsible for accepting email messages on behalf of a domain name. By changing the MX record, the engineer can direct all incoming email traffic to the CES gateway, where it can be filtered and scanned for threats before being delivered to the Microsoft Office 365 mailboxes. The other options are not relevant for this task. A CNAME record is a DNS record that maps an alias name to a canonical name. An SPF record is a DNS record that identifies the authorized senders of email for a domain. A DKIM record is a DNS record that contains a public key for verifying the digital signature of email messages sent from a domain. References :=

Some possible references for this question are:

Configure Microsoft 365 with Secure Email

Configure Microsoft 365 with Secure Email - More

[Cisco Cloud Email Security - Configuration Guide]

RADIUS Change of Authorization (CoA) is a feature of Cisco ASA that allows VPN users to be postured against Cisco ISE without requiring an inline posture node. RADIUS CoA enables the ISE to send a message to the ASA to change the authorization attributes of an existing VPN session, such as the assigned IP address, ACL, or group policy. This way, the ISE can dynamically adjust the access level of the VPN user based on the posture assessment results, without the need for an intermediate device to enforce the policy change12. RADIUS CoA is supported by the ASA since version 9.2.13. References: 1: ASA Version 9.2.1 VPN Posture with ISE Configuration Example - Cisco 2: How To: ISE and ASA Integration using CoA for Posture - Cisco Community 3: How To Configure Posture with AnyConnect Compliance … - Cisco CommunityQUESTION NO: 94

What two mechanisms are used to redirect users to a web portal to authenticate to ISE for guest services?

(Choose two)

A. multiple factor auth

B. local web auth

C. single sign-on

D. central web auth

E. TACACS+

Answer: B, D

 Local web authentication (LWA) and central web authentication (CWA) are two mechanisms that are used to redirect users to a web portal to authenticate to ISE for guest services. Both methods involve the use of a redirect access control list (ACL) that allows the user to access only the web portal URL and blocks all other traffic until the user is authenticated. The difference between LWA and CWA is where the web portal and the authentication logic are hosted.

LWA: The web portal and the authentication logic are hosted on the wireless LAN controller (WLC). The WLC sends a RADIUS access-accept message to the network access device (NAD) along with the redirect ACL and the web portal URL. The NAD then redirects the user to the web portal on the WLC, where the user enters their credentials. The WLC verifies the credentials with the ISE and grants or denies access to the user. The advantage of LWA is that it does not require any configuration on the ISE, but the disadvantage is that it does not support advanced features such as posture assessment, profiling, or authorization policies.

CWA: The web portal and the authentication logic are hosted on the ISE. The WLC sends a RADIUS access-challenge message to the NAD along with the redirect ACL and the web portal URL. The NAD then redirects the user to the web portal on the ISE, where the user enters their credentials. The ISE verifies the credentials and sends a RADIUS access-accept message to the WLC with the authorization profile and the final ACL. The WLC then applies the authorization profile and the final ACL to the user session. The advantage of CWA is that it supports advanced features such as posture assessment, profiling, or authorization policies, but the disadvantage is that it requires more configuration on the ISE.

References :=

Configure Guest Access

Web Authentication Redirection to Original URL

Configure Local Web Authentication with External Authentication
