Cisco Updated 350-701 Exam Questions and Answers by hawa

The missing global command is dot1x system-auth-control, which activates 802.1X processing on the switch. The access interfaces must also operate as Port Access Entity authenticators, so dot1x pae authenticator is required on ports connected to workstation supplicants. Cisco’s Catalyst 9300 802.1X configuration guide identifies the global command and the interface PAE role as elements of port-based authentication. Dynamic authorization supports Change of Authorization and is not required to initiate authentication. A RADIUS source interface is unnecessary when connectivity and RADIUS addressing already work. The mab command enables MAC Authentication Bypass for devices without an 802.1X supplicant; these workstations have functioning supplicants, so MAB is not the missing 802.1X control. Thus, A and C address the failure described.

================

To implement external authentication against Active Directory, the Cisco ISE server needs to communicate with the domain controller using either RADIUS or LDAP protocols. RADIUS is used for network access control, while LDAP is used for identity management and directory services. Both protocols require the appropriate ports to be opened and firewall rules to be configured to allow the traffic between the ISE server and the domain controller.

The ISE account does not need to be a domain administrator in Active Directory to perform JOIN operations. It only needs to have the permissions to create computer objects and reset passwords in the domain. This can be achieved by delegating the rights to a specific OU or using a service account with limited privileges.

Active Directory supports user and machine authentication by using various methods, not only MSCHAPv2. MSCHAPv2 is a challenge-response authentication protocol that is commonly used with RADIUS and VPN connections. However, Active Directory also supports other protocols such as Kerberos, NTLM, EAP, and PEAP, depending on the scenario and the client capabilities.

The Cisco ASA and the Cisco IOS router with Zone-Based Policy Firewall (ZFW) have different default behaviors when it comes to traffic filtering. The Cisco ASA follows a default deny-all policy that prohibits traffic between firewall security zones until an explicit policy is applied to allow desirable traffic1. The Cisco IOS router with ZFW, on the other hand, starts out by allowing all traffic, even on untrusted interfaces, until a zone-pair policy is applied to restrict or inspect traffic2. This means that the Cisco ASA provides a higher level of security by default, while the Cisco IOS router with ZFW requires more configuration to harden the router. However, the Cisco IOS router with ZFW also offers more flexibility and granularity in defining firewall policies, as well as more advanced features such as DMVPN, GET VPN, and Policy-Based Routing, which are not supported by the Cisco ASA23. References:

2: IOS Firewall vs. ASA - Cisco Community

1: Understand the Zone-Based Policy Firewall Design - Cisco

4: What is a functional difference between a Cisco ASA and a Cisco IOS router with Zone-based policy firewall?

5: What is a functional difference between a Cisco ASA and Cisco IOS router with Zone-based policy firewall?

3: Cisco Zone-Based Firewall Reporting – Plixer

VMware APIC is a platform that integrates with Cisco ACI to provide enhanced visibility, policy integration and deployment, and security policies with access lists. VMware APIC is a virtual appliance that runs on VMware vSphere and communicates with the Cisco APIC controller. VMware APIC allows administrators to create and manage Cisco ACI policies for VMware virtual machines and networks. VMware APIC also provides a unified view of the physical and virtual network topology, health, and statistics. VMware APIC supports the following modes of Cisco ACI and VMware integration:

VMware VDS: When integrated with Cisco ACI, the VMware vSphere Distributed Switch (VDS) enables administrators to configure VM networking in the ACI fabric.

Cisco ACI Virtual Edge: Cisco ACI Virtual Edge is a distributed service that provides Layer 4 to Layer 7 services for applications running on VMware vSphere.

Cisco Application Virtual Switch (AVS): Cisco AVS is a distributed virtual switch that provides policy-based network services for VMware vSphere environments. References:

Cisco ACI with VMware VDS Integration

Cisco ACI and VMware NSX-T Data Center Integration

Cisco ACI and VMware: The Perfect Pair

Setting the Record Straight: Confusion about ACI on VMware Technologies
