to configure GigabitEthernet0/1 as promiscuous port, GigabitEthernet0/2 as isolated port and GigabitEthernet0/3 and GrgabitEthernet0/4 as community ports. This way, the default gateway can communicate with all servers, the isolated port can only communicate with the promiscuous port, and the community ports can communicate with each other and the promiscuous port. This prevents the file server from communicating with the DNS servers, as required by the question.

To understand the concept of private VLANs and port types, you can refer to the following sections of the source book:

Section 1.1.2: Describe the concepts of network security

Section 1.1.2.1: Describe the concepts of private VLANs

Section 1.1.2.2: Describe the concepts of port types

Section 1.1.2.3: Describe the concepts of PVLAN edge

Section 1.1.2.4: Describe the concepts of protected ports

Section 1.1.2.5: Describe the concepts of PVLAN configuration

A network administrator can transparently identify users using Active Directory on the Cisco WSA in two ways:

Create NTLM or Kerberos authentication realm and enable transparent user identification. This option allows the WSA to use the NTLM or Kerberos protocol to authenticate users without prompting them for credentials. The WSA must join the Active Directory domain and have a valid service principal name (SPN) for this option to work1.

Deploy a separate Active Directory agent such as Cisco Context Directory Agent (CDA). This option allows the WSA to receive user-to-IP mappings from the CDA, which monitors the Active Directory domain controllers for user logon events. The CDA must be installed on a Windows server and have access to the domain controllers and the WSA2.

The other options are not ways to transparently identify users using Active Directory on the Cisco WSA. Creating an LDAP authentication realm and disabling transparent user identification will require users to enter their credentials manually. Installing the eDirectory client on each client workstation or deploying a separate eDirectory server are not related to Active Directory, but to Novell eDirectory, which is a different directory service3.

References := 1: User Guide for AsyncOS 11.0 for Cisco Web Security Appliances, Chapter: Acquire End-User Credentials, Topic: Active Directory/Kerberos, page 4-3. 2: User Guide for AsyncOS 11.0 for Cisco Web Security Appliances, Chapter: Acquire End-User Credentials, Topic: Active Directory Agent, page 4-5. 3: User Guide for AsyncOS 11.0 for Cisco Web Security Appliances, Chapter: Acquire End-User Credentials, Topic: eDirectory, page 4-8.

The issue is that the engineer is using the wrong hashing algorithm to generate the hash for the custom detection policy. Cisco AMP for Endpoints requires the use of SHA-256 hashes for simple custom detections, as stated in the Configure a Simple Custom Detection List on the AMP for Endpoints Portal document. SHA-256 hashes are 64 hexadecimal characters long, while MD5 hashes are 32 hexadecimal characters long. Therefore, if the engineer tries to upload a hash created using MD5, the dashboard will indicate that the hash is not 64 characters and is non-zero, as shown in the image below:

To resolve the issue, the engineer should use a tool or a website that can generate SHA-256 hashes from files, such as this one, and upload the correct hash to the custom detection list. References : Configure a Simple Custom Detection List on the AMP for Endpoints Portal, Create an Advanced Custom Detection List in Cisco Secure Endpoint, Working with Advanced Malware Protection (AMP) for Endpoints
