To filter traffic between multiple subnets, the engineer must implement the firewall in routed mode. In routed mode, the firewall operates as a Layer 3 device, capable of routing traffic between different IP subnets. This mode is appropriate for filtering traffic between LAN, DMZ, and WAN subnets.

Steps to configure routed mode:

Access the firewall's management interface.

Configure interfaces for each subnet (LAN, DMZ, WAN) with appropriate IP addresses and network masks.

Define security zones and apply access control policies to filter traffic as required.

This ensures that the firewall can inspect and route traffic between the different subnets, providing the necessary security and control.

To configure IPS mode on a Cisco Secure Firewall Threat Defense (FTD) device to inspect traffic and act as an IDS, the network engineer must configure an intrusion policy on the FTD device. The passive-interface and SPAN on the switch have already been configured, which means the traffic is being mirrored to the FTD. The next step is to set up an intrusion policy that defines the rules and actions for detecting and responding to malicious traffic.

Steps:

In FMC, navigate toPolicies > Intrusion.

Create a new intrusion policy or edit an existing one.

Define the rules and actions for detecting threats.

Apply the intrusion policy to the relevant interfaces or access control policies.

This configuration enables the FTD to inspect the mirrored traffic and take appropriate actions based on the defined intrusion policy.
