A switch is the network device that controls and forwards traffic primarily based on MAC addresses. In CompTIA A+ Core 1 networking, a switch operates at Layer 2 (Data Link) of the OSI model. When devices communicate on an Ethernet LAN, the switch learns the source MAC addresses from incoming frames and stores them in a MAC address table (CAM table) along with the port where each device is connected. After learning, the switch uses the destination MAC address in each Ethernet frame to decide which specific port should receive the traffic, which reduces unnecessary transmissions and improves overall network efficiency compared to a hub. If the destination MAC is unknown, the switch will flood the frame out other ports (except the one it came in on) until it learns the correct location.

A router makes forwarding decisions using IP addresses at Layer 3, not MAC-based switching decisions. A PoE injector only supplies electrical power over Ethernet and does not manage traffic forwarding. A firewall filters traffic based on rules (IP, ports, protocols, and sometimes application/state), but the classic CompTIA A+ answer for MAC-based traffic control on a LAN is a switch.

The 12VHPWR connector can supply up to 600 watts of power, designed for high-end graphics cards.

Why Not A (400W): This is less than the connector’s maximum capability.

Why Not B (MOW): This is an invalid option.

Why Not D (700W): The maximum supported power is 600W.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 3.4, power supply and connectors​.

F-type connectors are commonly used to terminate coaxial cables in cable internet, cable TV, and satellite connections.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.1 – Network cables and connectors:

“F-type connectors are used for coaxial cable terminations in cable modem and TV installations.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: Networking Cables and Connectors

CompTIA Exam Objectives 220-1101, Domain 3.1

============

If newly installed RAM is not fully recognized, the most likely cause is incorrect installation or incompatible slots. Reseating or reinstalling the RAM modules in the correct slots can quickly resolve the issue without extra cost.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.2 – Install and configure PC components:

" If memory is not detected, check installation and reseat modules. Ensure they are placed in the correct, matched slots for dual-channel operation. "

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: Memory Installation

CompTIA Exam Objectives 220-1101, Domain 3.2

============
