When a newly built workstation shows no response at all—no fans spinning, no indicator LEDs, and no POST activity—this indicates that the system is not receiving the signal to power on. Since the technician has already verified that all primary power connectors are fully seated (including the 24-pin ATX motherboard connector and the 4-pin or 8-pin CPU power connector), the most likely cause is that the case header pins are not connected to the motherboard.

According to CompTIA Core 1 (220-1201) hardware installation and troubleshooting concepts, the power button on the computer case connects to the motherboard via the front-panel (system panel) header, specifically the PWR_SW pins. If this connector is missing, improperly placed, or connected to the wrong pins, pressing the power button will do nothing because the motherboard never receives the power-on signal.

Incorrectly seated RAM typically allows the system to power on but prevents successful POST, often resulting in beep codes or error lights. An underpowered PSU usually causes instability, random shutdowns, or failure under load rather than complete inactivity. A faulty CPU fan connector generally triggers a BIOS warning or shutdown after power-on, not total failure to start.

This scenario directly matches CompTIA’s emphasis on checking front-panel connections as a primary step when a system does not power on at all.

Excessive heat buildup due to insufficient cooling is a primary cause of unexpected shutdowns. A high-performance heat sink improves thermal transfer, dissipates more heat, and helps maintain CPU temperature within safe limits. When CPU temperatures reach levels like 208°F (98°C), the system may shut down to prevent damage.

Comprehensive and Detailed Step-by-Step Explanation:

To determine the correct device, we need to understand how a DOCSIS (Data Over Cable Service Interface Specification) network functions in a Small Office/Home Office (SOHO) environment:

C. Cable Modem:

A cable modem is required to convert the signal provided by the ISP (Internet Service Provider) over a DOCSIS network into a format that is usable by the local area network (LAN).

DOCSIS is a standard for high-speed internet over cable television infrastructure, and the cable modem acts as the gateway between the ISP ' s coaxial network and the LAN.

Without the cable modem, devices in the LAN would not be able to access the internet.

For a gaming PC with multiple GPUs, the power supply must safely deliver high current on the 12V rails, since GPUs and CPUs draw most of their power from 12V. A multiple-rail power supply divides the 12V output into separate rails protected by overcurrent protection (OCP). This configuration helps prevent a single rail from being overloaded and can provide safer distribution when several high-draw components (multiple GPUs, high-end CPU) are installed. From a CompTIA A+ Core 1 perspective, selecting PSU characteristics that match system load and expansion needs is key, and multi-rail designs are directly related to supporting multiple high-power devices with better protection controls.

The other options do not meet the goal. Redundant PSUs are typically used in servers for uptime, not consumer gaming builds, and they don’t inherently address GPU power distribution. Non-modular only affects cable management and airflow, not power capability or scalability. Low wattage directly conflicts with the requirement for multi-GPU performance and future upgrades. Therefore, the best choice given is multiple-rail.
