HCIP-Datacom-Core Technology V1.0 H12-821_V1.0 Exam Questions with Experts Answers Updated Recently

Comprehensive and Detailed Step-by-Step Explanation:

1. Understanding the IGMP Group Entry:

The IGMP group entry contains key information about multicast groups on the interface:

Group Address (225.1.1.2): The multicast group address that the user has joined.

Last Reporter (10.1.6.10): The IP address of the last host that sent an IGMP Report message for this group.

Uptime: The duration since the group was first reported.

Expires: The remaining time before the group entry ages out if no further reports are received.

2. Analysis of Each Statement:

Option A: This entry can be used to construct the corresponding (S, G) entry.

Incorrect.

This is a group entry for IGMP, which contains information about the group (G) but does not include a specific source (S). (S, G) entries are created in PIM (Protocol Independent Multicast), not IGMP.

Option B: This entry is created when the device receives an IGMP Join message from a user.

Correct.

IGMP Join messages are used by hosts to signal their intent to join a multicast group. When such a message is received, the group entry is created.

Option C: Expires indicates the aging time of the IGMP group.

Correct.

The " Expires " field shows the remaining time before the group entry ages out if no further IGMP reports are received.

Option D: 225.1.1.2 is the address of the group that the user joins.

Correct.

The " Group Address " field explicitly states that 225.1.1.2 is the multicast group that the user has joined.

3. Summary:

Correct Options: B, C, D

A is correct – Confederations are specifically designed for large-scale BGP deployments where a full IBGP mesh is impractical.

B is correct – Sub-ASs within a confederation establish EBGP-like connections between each other but behave like IBGP within the overall AS. These sub-ASs do not require full-mesh inside the confederation , but EBGP rules are followed between sub-ASs.

C is false – Not all devices need to be reconfigured . Devices within the same sub-AS retain normal IBGP behavior and minimal changes.

D is correct – Confederation is transparent to external peers , so the logical topology remains the same from outside the AS.

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“BGP confederation divides an AS into multiple sub-ASs. EBGP-like sessions are established between sub-ASs, while reducing IBGP mesh complexity. The external AS still sees the AS as one unit.”

(Chapter: BGP Scalability Enhancements – Section: Confederation)
