Question 80

In an OSPF routing domain, two routers must be specified as one DR and one BDR in a broadcast or NBMA network with at least two routers.

Options:

TRUE

FALSE

Discussion

Question 81

From the logical architecture perspective, network devices are logically divided into multiple planes. Which of the following planes is not one of them?

Options:

Forwarding plane

Monitoring plane

Data plane

Control plane

Discussion

Question 82

On an OSPF network, an algorithm is used to prevent loops within an area, but loops may occur between areas. Therefore, OSPF defines a loop prevention mechanism for inter-area routes. Which of the following statements are true about the loop prevention mechanism?

Options:

Inter-area routes cannot be directly transmitted between non-backbone areas.

All non-backbone areas must be directly connected to area 0.

Inter-area routes need to be forwarded through area 0.

An ABR cannot inject Type 3 LSAs that describe routes to a network segment in an area back to the same area.

Discussion

Answer:

A, B, C, D

Explanation:

 OSPF Area Design and Loop Prevention:

OSPF uses a hierarchical structure with areas to improve scalability and efficiency. Area 0, the backbone area, plays a crucial role in ensuring loop-free route distribution between areas. The following mechanisms are key to preventing routing loops:

Strict adherence to hierarchical area design.

Prohibition of direct inter-area route exchanges between non-backbone areas.

HCIP-Datacom-Core Technology Training Material (OSPF Basics and Advanced Concepts).

 Analysis of Each Statement:

A. Inter-area routes cannot be directly transmitted between non-backbone areas.This statement is TRUE. OSPF mandates that all inter-area routing must pass through Area 0. Direct inter-area route exchanges between two non-backbone areas are not allowed to prevent loops.

[Reference: HCIP-Datacom-Core Technology Training Material (Inter-Area Routing Mechanisms)., B. All non-backbone areas must be directly connected to area 0.This statement is TRUE. OSPF requires every non-backbone area to connect directly to Area 0 to facilitate loop-free inter-area routing. Virtual links may be configured in exceptional cases where direct connection is not possible., Reference: HCIP-Datacom-Core Technology Training Material (OSPF Backbone and Area Connectivity)., C. Inter-area routes need to be forwarded through area 0.This statement is TRUE. All inter-area traffic must traverse Area 0 to ensure hierarchical routing and loop prevention. This rule is a core design principle of OSPF., Reference: HCIP-Datacom-Core Technology Training Material (Routing Control and Loop Prevention in OSPF)., D. An ABR cannot inject Type 3 LSAs that describe routes to a network segment in an area back to the same area.This statement is TRUE. OSPF explicitly prohibits an ABR from injecting Type 3 LSAs describing a route into the same area where the route originates. This mechanism prevents routing loops within an area., Reference: HCIP-Datacom Advanced Routing & Switching Technology (OSPF LSA Types and ABR Behavior).,  Conclusion:All options (A, B, C, D) are correct. OSPF enforces a robust loop prevention mechanism through hierarchical routing, mandatory traversal via Area 0, and strict rules on LSA propagation by ABRs. This ensures reliable and loop-free inter-area routing in OSPF networks., , ]

Honey

I highly recommend it. They made a big difference for me and I'm sure they'll help you too. Just make sure to use them wisely and not solely rely on them. They should be used as a supplement to your regular studies.

Antoni Sep 12, 2026

Good point. Thanks for the advice. I'll definitely keep that in mind.

Joey

I highly recommend Cramkey Dumps to anyone preparing for the certification exam. They have all the key information you need and the questions are very similar to what you'll see on the actual exam.

Dexter Sep 18, 2026

Agreed. It's definitely worth checking out if you're looking for a comprehensive and reliable study resource.

Stefan

Thank you so much Cramkey I passed my exam today due to your highly up to date dumps.

Ocean Sep 8, 2026

Agree….Cramkey Dumps are constantly updated based on changes in the exams. They also have a team of experts who regularly review the materials to ensure their accuracy and relevance. This way, you can be sure you're studying the most up-to-date information available.

Miley

Hey, I tried Cramkey Dumps for my IT certification exam. They are really awesome and helped me pass my exam with wonderful score.

Megan Sep 16, 2026

That’s great!!! I’ll definitely give it a try. Thanks!!!

Question 83

The figure shows the VRRP status switchover events. Match these events with their sequence numbers.

Questions 83
