 MQC and PBR

MQC (Modular QoS Command-Line Interface): Applied to interfaces for classifying and controlling traffic.

PBR (Policy-Based Routing): Used to influence packet forwarding based on policies rather than traditional routing tables.

Both MQC and PBR can be configured on device interfaces to filter incoming/outgoing packets or control their forwarding paths.

 HCIP-Datacom-Core Reference

The use of MQC and PBR on device interfaces is elaborated in the QoS and routing control chapters​​.

Comprehensive and Detailed Step-by-Step Explanation:

1. Understanding IGMP (Internet Group Management Protocol):

IGMP is used in multicast networking to manage membership of devices in multicast groups.

Key parameters in the configuration provided:

Interface IP Address: 192.168.1.1

IGMP Version: 2

Query Interval (Configured): 60 seconds

Maximum Query Response Time: 10 seconds

Querier Address: 192.168.1.1

2. Analysis of Each Statement:

Option A: The IP address of the interface is 192.168.1.1.

Correct (True Statement).

The configuration clearly shows that the IP address of the interface is 192.168.1.1.

Option B: The maximum response time to Query messages is 10s.

Correct (True Statement).

The configuration explicitly mentions: Value of maximum query response time for IGMP: 10 s.

Option C: The interval for sending Group-Specific Query messages is 60s.

Incorrect (False Statement).

The 60-second value refers to the query interval, which is the time interval between general queries sent by the querier.

The interval for group-specific queries is not specified in this configuration. It is determined dynamically based on the multicast environment and is usually shorter than the general query interval.

Option D: The IGMP version is IGMPv2.

Correct (True Statement).

The configuration specifies: Current IGMP version is 2.

3. Why Option C is False:

The 60-second value is for general query interval, not group-specific query interval.

The statement misinterprets the configuration, making it false.

4. Summary:

Correct Answer: C (The interval for sending Group-Specific Query messages is 60s).

Understanding the LSDB and Level-2 DIS Election in IS-IS:

In IS-IS, the Designated Intermediate System (DIS) is elected for both Level-1 and Level-2 on broadcast networks to manage the link-state database (LSDB) and reduce the number of LSAs exchanged.

The election of the DIS is based on the highest priority. If the priority is the same, the router with the highest System ID becomes the DIS.

Attributes such as community, tag, and origin can be directly referenced in the apply clause of a route-policy. However, IP-prefix is not an attribute but a prefix list used for matching, and it cannot be directly applied ​.
