The Designated Intermediate System (DIS) in an IS-IS broadcast network sends Complete Sequence Number PDUs (CSNPs) at a default interval of 30 seconds. This interval ensures periodic synchronization of the Link State Database (LSDB) among IS-IS neighbors ​.

The question indicates that a router performs a lookup in its FIB table for a packet and determines that the tunnel ID in the matching entry is 0, suggesting that the packet needs to be forwarded through a tunnel such as an MPLS tunnel. However, this is a misunderstanding of the FIB functionality.

FIB Table Overview The Forwarding Information Base (FIB) is used to make packet-forwarding decisions. Entries in the FIB include next-hop information, which can be directly linked to an interface or a tunnel.

If the Tunnel ID is 0 , it indicates that the packet is forwarded via a normal routing path and not through a tunnel.

For MPLS or other tunnels, the Tunnel ID would have a non-zero value pointing to the associated tunnel.

MPLS Tunnel Operation When a router forwards packets through an MPLS tunnel, a label-switched path (LSP) is set up. The FIB would reflect specific tunnel identifiers for packets that need such encapsulation.

HCIP-Datacom-Core Reference

Routing Principles and MPLS ​explain the forwarding mechanisms clearly, stating that if a packet is routed normally, the tunnel ID remains 0 .

The section on MPLS​clarifies the encapsulation process and the role of tunnel identifiers.

Hence, the claim in the question is incorrect. A Tunnel ID of 0 implies no tunneling is required, and normal IP forwarding occurs
