Microsoft Updated AZ-700 Exam Questions and Answers by edison

You have an Azure subscription that contains a virtual network named VNet1. VNet1 contains the following subnets.

• AzureFirewallSubnet

• GatewaySubnet

• Subnet 1

• Subnet2

• Subnet3

Subnet2 has a delegation to the Microsoft.Web/serverfarms service. The subscription contains the resources shown in the following table.

You need to implement an Azure application gateway named AG1 that will be integrated with an Azure Web Application Firewall (WAF). AG1 will be used to publish VMSS1.

To which subnet should you connect AG1?

You have an Azure subscription.

You plan to implement Azure Virtual WAN as shown in the following exhibit.

What is the minimum number of route tables that you should create?

You have two Azure virtual networks named VNet1 and VNet2 that are peered with each other. VNet1 hosts 10 virtual machines that contain web servers. VNet2 hosts five virtual machines that contain database servers.

You need to configure a security solution that meets the following requirements:

• Ensures that the database servers can accept connections only from the web servers

• Ensures that the web servers can initiate connections only to the database servers

• Ensures that all network security groups (NSGs) are associated only with subnets

• Use application security groups to implement the solution

What is the minimum number of application security groups required?

Note: This question is part of a series of questions that present the same scenario. Each question in the series contains a unique solution that might meet the stated goals. Some question sets might have more than one correct solution, while others might not have a correct solution.

After you answer a question in this section, you will NOT be able to return to it. As a result, these questions will not appear in the review screen.

You have an Azure application gateway that has Azure Web Application Firewall (WAF) enabled.

You configure the application gateway to direct traffic to the URL of the application gateway.

You attempt to access the URL and receive an HTTP 403 error. You view the diagnostics log and discover the following error.

You need to ensure that the URL is accessible through the application gateway.

Solution: You disable the WAF rule that has a ruleld of 920300.

Does this meet the goal?
