Cisco Updated 300-420 Exam Questions and Answers by rhea

MSDP is the correct technology when a large multicast design uses multiple PIM Sparse Mode domains and needs to exchange active source information between those domains. Cisco describes Multicast Source Discovery Protocol as the mechanism used by RPs in different PIM-SM domains to learn about multicast sources outside their own domain. When a source becomes active, the local RP can advertise Source-Active information to MSDP peers, allowing receivers in other domains to discover and join that source. This supports domain separation and can help balance multicast control-plane scope in large networks. DVMRP and MOSPF are legacy multicast routing approaches and are not the design mechanism for modern PIM-SM domain interconnection. IGMP is used between hosts and local multicast routers for receiver membership signaling; it does not exchange source information between multicast domains. Therefore, a design with more than 100 routers, several multicast domains, and PIM-SM traffic balancing should include MSDP. The architect should also design RP placement, Anycast RP behavior, peer mesh scaling, and source filtering. Reference topics: MSDP, PIM-SM domains, Source-Active messages, interdomain multicast.

Network management traffic should be marked and treated as a dedicated operations class, not mixed into voice signaling or real-time queues. Cisco enterprise QoS design guidance commonly reserves DSCP CS2 for operations, administration, and management traffic such as SNMP, SSH, syslog, NTP, and other management flows. The question states that all eight queuing classes are already used, so the design should integrate management traffic into the closest existing class and validate that the queue has enough bandwidth. Option D is the best fit because it uses CS2 and requires baselining before allocating more bandwidth. CS6 is normally used for network control and routing protocols; using it for ordinary management traffic would compete with routing adjacencies and control-plane stability. CS5 and CS4 are also unsuitable because they are normally associated with video/signaling-related classes in many enterprise QoS models. The professional design action is to classify management traffic explicitly, mark it CS2 at the trust boundary, map it to the existing class, and then measure queue utilization before changing bandwidth allocations. Reference topics: Cisco QoS baseline, DSCP CS2, network management traffic, queue bandwidth design.

VRF-Lite with OSPF satisfies the requirements because it creates multiple isolated Layer 3 routing tables without requiring a service-provider MPLS core or specialized hardware. Each VRF has its own forwarding table, interfaces, and route exchange process, so overlapping IP address space can exist in different virtual networks. When communication between segments is required, the design can use controlled route leaking, a firewall, or a shared-services VRF. OSPF can run per VRF to exchange routes within each isolated segment using widely supported routing technology. VSS, vPC, and plain 802.1Q with HSRP can improve Layer 2 or device redundancy, but they do not provide independent Layer 3 routing tables with overlapping addressing. A multihop MPLS design can also support many VPNs, but it is more complex and beyond the stated need for widely available technologies without specialized equipment. VRF-Lite is therefore the correct enterprise campus segmentation choice. Reference topics: VRF-Lite, virtual routing and forwarding, inter-VRF routing, overlapping IP address support, campus segmentation.

A policy-based IPsec tunnel with static routing is the simplest secure design for connecting two hosts in two companies when no additional future connectivity is planned. The requirement is narrow: one host in Company A must communicate with one host in Company B over a single encrypted Internet connection. Policy-based IPsec is straightforward for this type of point-to-point encryption because crypto ACLs define exactly which interesting traffic should be protected. Static routing is sufficient because there is no complex topology, no dynamic path selection requirement, and no anticipated expansion. A DMVPN design would add unnecessary NHRP, multipoint GRE, and dynamic routing complexity. A routed IPsec tunnel with OSPF is useful when many networks or dynamic route changes are expected, but it is more complex than needed. MPLS VPN with BGP would require provider service and does not meet the simple encrypted Internet connection requirement. Reference topics: site-to-site IPsec, policy-based VPN, static routing, point-to-point secure connectivity, WAN simplicity.
