According to the FortiSwitchOS 7.6 Administration Guide and the FortiSwitch 7.6 Study Guide , the Loop Guard feature protects Layer 2 networks from switching loops and broadcast storms. Unlike standard STP loop protection mechanisms, FortiSwitch Loop Guard operates by periodically sending out proprietary Loop Guard Data Packets (LGDP) / probe frames out of ports where loop guard is enabled.

The loop-detection logic evaluates whether these probe frames return to the switch:

Frame Received Back on the Same Port (Option B): If a loop guard broadcast frame transmitted out of port1 traverses an external unmanaged hub, switch, or looped cable and is received back on port1, the switch detects a downstream loop directly connected to that port.

Frame Received on Another Port of the Same Switch (Option A): In multi-homed connections to a switched network (such as port1 and port2 sharing the same Layer 2 broadcast domains/VLANs), a loop guard frame sent from port1 that loops through the switched network and is received on port2 proves that an active Layer 2 loop exists between those two switch interfaces.

When a loop condition is verified by either scenario, FortiSwitch changes the status of the protected port to Triggered (as verified in the CLI output of the exhibit) and takes the port out of service to isolate the loop.

Regarding the incorrect options: Option C describes Spanning Tree loop guard behavior (loss of BPDUs on non-designated ports), not the FortiSwitch proprietary loop guard mechanism. Option D describes Storm Control or rate limiting, which acts on packet volume thresholds rather than loop-detection probe frames.

Switch-controller-dhcp-snooping-verify-mac verifies the destination MAC address to protect against DHCP exhaustion attacks (B): This feature of DHCP snooping helps prevent DHCP exhaustion attacks by ensuring that the destination MAC addresses in DHCP packets match the MAC addresses learned by the switch. This check helps prevent attackers from overwhelming the DHCP server with requests from spoofed MAC addresses.

Settings related to DHCP option 82 are only configurable through the CLI (D): DHCP Option 82 is used for " agent information, " and it ' s typically used in network environments where additional information between DHCP clients and servers is necessary for policy and billing purposes. Configuration of these settings in FortiSwitch is only available through the Command Line Interface (CLI), not the Graphical User Interface (GUI).

According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, the output of the diagnose stp instance list command provides critical information about the Spanning Tree Protocol (STP) state of a switch within a given instance. In the provided exhibit, the output forInstance ID 0 (CST)onCore-2shows several key indicators of its role and connectivity within the STP topology.

First, the output explicitly identifies aRootbridge with MAC address 02090f000701 and a priority of 4096. Core-2 itself has a MAC address of 02090f000702 and a priority of 32768. Because Core-2 knows the MAC address and priority of the Root bridge, it must have received this information viaBridge Protocol Data Units (BPDUs). Furthermore, the port table shows thatport3on Core-2 has been assigned the role ofROOTand is in theFORWARDINGstate. In STP/RSTP, a Root Port is the port on a non-root switch that has the lowest path cost to the root bridge. To elect a Root Port and maintain its state, the switch must continuously receive BPDUs from the root bridge (or a bridge closer to the root) on that port.

Option B is incorrect because Core-2 has aRoot Port, which is only present on non-root bridges. Option C is incorrect because ports 1, 2, 4, 5, and the internal port are all in theFORWARDINGstate. Option D is incorrect as the output does not show any ports in anALTERNATErole; all active ports are either ROOT or DESIGNATED. Therefore, the most accurate conclusion is that Core-2 has successfully received BPDUs to identify the root and determine its own port roles.

While FortiSwitch can collect all the listed LLDP-MED TLVs (Network Policy, Power Management, Location, and Inventory Management), the primary focus for tracking and identifying network devices is on theInventory ManagementTLV.

This TLV carries critical details such as:

Manufacturer

Model

Hardware/Firmware versions

Serial/Asset numbers

This information provides a granular understanding of the devices on your network.
