VMware Updated 3V0-24.25 Exam Questions and Answers by ema

In Kubernetes, the component that actuallycreates and runs workloads on a nodeis thekubelet. The kubelet is the node agent that ensures the containers described by PodSpecs are running on that node. VCF 9.0 maps this concept directly into vSphere Supervisor by describingSphereletas “a kubelet that is ported natively to ESXi and allows the ESXi host to become part of the Kubernetes cluster,” showing that kubelet functionality is responsible for running workloads on worker nodes (ESXi hosts in the Supervisor case).

The other options have different roles:etcdis the control plane data store,API Serveris the front-end for Kubernetes API operations, and theSchedulerdecides placement (which node should run a pod). VCF 9.0 even calls out that “the Kubernetes scheduler… cannot place pods intelligently” without visibility into vCenter inventory—reinforcing that scheduling is about placement decisions, not the act of creating/running the workload on the node.

So, while the scheduler selects where a pod should run, thekubeletis the component responsible for actually instantiating and maintaining the workload on the target node.

Contour is a high-performance Ingress controller for Kubernetes that serves as the control plane for the Envoy edge and service proxy. Within the VMware Cloud Foundation (VCF) 9.0 and vSphere Kubernetes Service (VKS) architecture, Contour is a critical component used to manage how external traffic reaches services running inside a cluster. It functions specifically at the application layer (Layer 7 of the OSI model), enabling sophisticated routing based on HTTP paths, hostnames, and headers.

By utilizing the Envoy proxy, Contour provides a scalable and maintainable way to handle standard Kubernetes Ingress resources as well as the more advanced HTTPProxy custom resource definitions (CRDs). In a VKS environment, once the Supervisor is configured and a workload cluster is deployed, Contour is typically installed as a managed package to provide ingress services. It handles essential tasks such as SSL/TLS termination, which offloads the encryption overhead from individual application pods, and supports advanced traffic management patterns like canary deployments or blue-green updates. Unlike traditional load balancers that may operate only at Layer 4, Contour’s deep integration with the Kubernetes API allows it to dynamically update routing rules as pods scale or fail, ensuring high availability and fine-grained control for containerized applications. This makes it the standard solution for application-layer ingress management across the VMware Tanzu and VKS ecosystem.

VCF 9.0 design guidance for theSupervisor NSX Load Balancer modelstates that theNSX load balancers run on NSX Edges, and sets explicit sizing requirements at theEdge nodelevel. In the “NSX Load Balancer Design Requirements,” VCF 9.0 requires that theNSX Edge cluster must be deployedbecause “NSX Load Balancers run on NSX Edges.” It further requires that“NSX Edge nodes must be deployed with a minimum of Large form factor”because NSX load balancers havefixed resource allocations on NSX Edge nodes, and the Large form factor is needed to accommodate basic system and workload needs.

This directly ties “deployment size” of the load balancer service capacity to theEdge node form factor(Small/Medium/Large, etc.) rather than the number of pods or the number of clusters. The document also notes that if additional load balancers are required, NSX Edges can bescaled up or out, again reinforcing that sizing is anEdge nodesizing decision.

When you build Kubernetes-aware policy constructs, “groups” are commonly used to collect objects so you can apply consistent controls (security posture, traffic rules, observability scope, etc.) to a set of endpoints. In VCF 9.0 documentation, the Kubernetes member types that can be used for group-based collection includeKubernetes NodeandKubernetes Serviceas supported member object categories. Nodes represent the worker compute endpoints that run workloads, while Services represent stable networking front-ends for sets of pods (and are often the anchoring object for policy and routing decisions at the Kubernetes layer). Using Node-based grouping helps apply policies to the infrastructure execution points where workloads run, and Service-based grouping helps apply policies consistently to application entry points and east-west communication targets, regardless of pod churn. This combination is especially useful in Kubernetes-centric operational models because it aligns policy scope with both (1) where workloads execute (nodes) and (2) how workloads are exposed and discovered (services).
