Huawei Updated H12-811_V1.0 Exam Questions and Answers by dario

Advanced ACLs (3000-3999) allow filtering based on:

Source and Destination IPs

Protocol Number (C - Correct)

Destination Port Number (B - Correct)

Time-range (D - Correct)

A (Incorrect): ACLs do not filter based on the source interface, but rather on IPs, ports, and protocols.

Thus, the correct answer is A (Source Interface).

Comprehensive Explanation: In RSTP (Rapid Spanning Tree Protocol), G0/0/3 of SWB is an Alternate Port because it provides a redundant path to the root bridge, while G0/0/3 of SWA is a Designated Port, forwarding traffic away from the root bridge. Similarly, G0/0/2 of SWA is also a Designated Port because it forwards traffic to other segments of the network. Alternate Ports are used to provide backup paths, while Designated Ports are the forwarding ports on a given segment.

Comprehensive Explanation: An ACL (Access Control List) is used to define rules for permitting or denying packets based on criteria such as IP addresses, protocols, or ports. However, the ACL only takes effect when it is applied to a service module, such as an interface or a firewall rule. This ensures that traffic is filtered according to the ACL rules as it passes through the device. Without being applied, the ACL rules are inactive and do not influence traffic.

The default Link Aggregation Control Protocol (LACP) system priority on Huawei switches is 32768. This priority helps determine which device takes the active role in link aggregation when multiple switches are involved. A lower value indicates a higher priority for managing the aggregated link​.
