The exhibit shows the output of the command  show ip bgp , which displays information about the BGP routes in the routing table 1 . The output shows two routes for the destination 192.168.10.0/24, one from R1 and one from R2.

The route from R1 has a local preference of 200, while the route from R2 has a local preference of 100.  Local preference is a BGP attribute that indicates the degree of preference for a route within an autonomous system (AS) 2 .  A higher local preference means a more preferred route 2 .

BGP uses a best path selection algorithm to choose the best route for each destination among multiple paths.  The algorithm compares different attributes of the routes in a specific order of precedence 3 .  The first attribute that is compared is weight, which is a Cisco-specific attribute that is local to the router 3 .  If the weight is equal or not set, the next attribute that is compared is local preference 3 .

In this case, both routes have the same weight of 0, which means that they are learned from external BGP (eBGP) peers 3 . Therefore, the next attribute that is compared is local preference.  Since R1’s route has a higher local preference than R2’s route, it is chosen as the best path and installed in the routing table 3 . The other attributes, such as origin code and AS path, are not considered in this case.

BGP is a routing protocol that operates between autonomous systems (AS). An AS is a group of routers under a single administrative control. BGP can be classified into two types: internal BGP (IBGP) and external BGP (EBGP). IBGP is the BGP communication between routers within the same AS, while EBGP is the BGP communication between routers in different AS. BGP uses the AS_PATH attribute to record the AS numbers that the route has passed through, and uses it to prevent routing loops and select the best path.

In this scenario, you want to add a second ISP connection and remove the default route to the existing ISP. This means that you want to have more control over the routing decisions and use BGP to exchange routes with both ISPs. To do this, you need to deploy the BGP protocol in your network and configure both IBGP and EBGP sessions. The correct statements about BGP in this scenario are:

IBGP peers advertise routes received from EBGP peers to other IBGP peers. This is the default behavior of IBGP, as it allows the routers within the same AS to learn the routes from different EBGP peers and select the best exit point. However, IBGP has a rule that it does not advertise routes received from IBGP peers to other IBGP peers, to avoid creating routing loops. Therefore, option B is correct and option C is incorrect. To overcome this rule, IBGP requires a full mesh topology, where every IBGP router is directly connected to every other IBGP router, or a route reflector or confederation design, where some IBGP routers act as intermediaries to reflect or aggregate the routes to other IBGP routers.

EBGP peers advertise routes received from IBGP peers to other EBGP peers. This is the default behavior of EBGP, as it allows the routers in different AS to exchange routes and reachability information. However, EBGP has a rule that it does not advertise routes received from EBGP peers to other EBGP peers, to avoid creating routing loops. Therefore, option D is correct and option A is incorrect. To overcome this rule, EBGP uses the AS_PATH attribute to filter out the routes that contain its own AS number, or uses route maps or policies to control the route advertisement. IBGP does not update the next-hop attribute to ensure reachability within an AS, as the next-hop attribute is preserved by IBGP. Instead, IBGP relies on an underlying IGP (Interior Gateway Protocol) to provide reachability to the next-hop.

IP-IP tunnels encapsulate IP packets within other IP packets, allowing them to traverse networks that wouldn ' t normally support the original IP packets. This encapsulation involves the TTL (Time-to-Live) of the inner packet being decremented as it traverses through the tunnel towards its endpoint.
