According to theSD-WAN 7.6 Core Administratorcurriculum and theFortiOS 7.6 Administration Guide, setting common web-based services like Facebook and LinkedIn as destinations in an SD-WAN rule is primarily accomplished through theInternet Service Database (ISDB).

Internet Service vs. Application Control: In FortiOS, there is a distinction betweenInternet Services(which use a database of known IP addresses and ports to identify traffic at the first packet) andApplications(which require the IPS engine to inspect deeper into the packet flow to identify Layer 7 signatures).

SD-WAN Efficiency: Fortinet recommends using theInternet service fieldfor services like Facebook and LinkedIn in SD-WAN rules because it allows the FortiGate to steer the traffic immediately upon the first packet. If the "Application" signatures were used instead, the first session might be misrouted because the application is not identified until after the initial handshake.

GUI Configuration: As shown in the exhibit (image_b3a4c2.png), the "Destination" section of an SD-WAN rule includes anInternet servicefield by default. To steer Facebook and LinkedIn traffic, the administrator simply clicks the "+" icon in that field and selects the entries for Facebook and LinkedIn from the database.

Feature Visibility (Alternative): While youcanenable a specific "Application" field inSystem > Feature Visibility(by enabling "Application Detection Based SD-WAN"), this is typically used for less common applications that do not have dedicated ISDB entries. For the specific "applications" mentioned (Facebook and LinkedIn), they are natively available in theInternet servicefield, making Option B the most direct and common implementation.

Why other options are incorrect:

Option A: Licensing for application signatures is part of the standard FortiGuard services and is not a prerequisite specific only to "applications as destinations" in SD-WAN rules.

Option C: Standalone FortiGate devices fully support application-based and ISDB-based steering in SD-WAN rules.

Option D: While enabling feature visibility would add anadditionalfield for L7 applications, it is not a "must" for Facebook and LinkedIn, which are already accessible via the Internet Service field provided in the default GUI layout.

According to theSD-WAN 7.6 Core Administratorstudy guide andFortiOS 7.6 Administration Guide, the "implicit rule" is the default rule at the bottom of the SD-WAN rule list (ID 0). It is only evaluated if traffic does not match any manually configured SD-WAN rules.

Policy Route Table Context (Option B): SD-WAN rules are technically a specialized form of policy-based routing. For a packet to match theimplicit rule, it must first pass through the routing hierarchy. If traffic matches the implicit rule, it indicates that it did not match any higher-priority user-defined SD-WAN rules or any specific entries in the manualpolicy route tablethat would have intercepted the traffic earlier.

Session Information (Option E): When you use the CLI to inspect an active session (e.g., diagnose sys session list), the output contains a field for theSD-WAN Service ID. If traffic is steered by a user-defined rule, it displays the ID of that rule (e.g., service_id=1). However, when traffic falls through to theimplicit rule, the session information displaysno SD-WAN service ID(it often shows as 0 or is omitted), because the implicit rule does not function as a "service" in the same way user-defined rules do.

Routing Behavior: The implicit rule follows the standard routing table (RIB/FIB) logic. It uses thepriorityanddistanceof the static routes to determine the path. If multiple paths have the same distance and priority, it uses the algorithm set by v4-ecmp-mode, but this is a function of the routing engine, not the SD-WAN engine itself.

Why other options are incorrect:

Option A: While v4-ecmp-mode (e.g., source-ip-based) is used for ECMP routing, this is part of the general FortiOS routing behavior for equal-cost paths in the FIB, whereas the implicit rule simply "hands over" the decision to that routing table.

Option C: When traffic matches the implicit rule, the session is actually flagged with vwl_id=0 and potentially dirty if a route change occurs, but vwl_default is not the standard flag name used in this specific context in the curriculum.

Option D: This is incorrect because the implicit ruledoes respect weight, distance, and priorityas defined in the static routes within the routing table; it does not distribute traffic "regardless" of these values.
