Fortinet Updated FCP_FAZ_AN-7.6 Exam Questions and Answers by sabrina

The study guide explains that in a Security Fabric,traffic logging is not duplicatedacross FortiGates for the same session:“Traffic logging for a session … is always carried out by the first FortiGate that handled it”and if a FortiGate receives traffic from a peer FortiGate MAC,“it does not generate a new traffic log for that session.”

For UTM (web filtering) logs, the study guide states:“When configured, upstream devices complete UTM logging.”

In the illustrated example, it further clarifies the role split:“All traffic from Client-1 is first received by FGT-B, which creates traffic logs for the initial session… [then] forwarded to FGT-A… [and] FGT-A … applies web filtering … and generates the relevant UTM logs as necessary.”

Because web filter profiles are configured tolog only violations, web filter (UTM) logs will be generated only when a violation is detected—and per the study guide behavior, that UTM logging is done by theupstreamFortiGate (FGT-A). Therefore,only FGT-A will create web filter logs if it detects a violation(Option D).

In FortiOS 7.4.1 and FortiAnalyzer 7.4.1, the "Unhandled" status in logs typically signifies that the FortiGate encountered a security event but did not take any specific action toblock or alter it. This usually occurs in the context of Intrusion Prevention System (IPS) logs.

IPS logs with action=pass:When the IPS engine inspects traffic and determines that it does not match any known attack signatures or violate any configured policies, it assigns the action "pass". Since no action is taken to block or modify this traffic, the status is logged as "Unhandled."

Let's look at why the other options are incorrect:

An AV log with action=quarantine:Antivirus (AV) logs with the action "quarantine" indicate that a file was detected as malicious and moved to quarantine. This is a definitive action, so the status wouldn't be "Unhandled."

A WebFilter log will action=dropped:WebFilter logs with the action "dropped" indicate that web traffic was blocked according to the configured web filtering policies. Again, this is a specific action taken, not an "Unhandled" event.

An AppControl log with action=blocked:Application Control logs with the action "blocked" mean that an application was denied access based on the defined application control rules. This is also a clear action, not "Unhandled."
