In Prisma SD-WAN, the Signal-to-Noise Ratio (SNR) is a critical metric used to monitor the health and performance of cellular WAN interfaces. SNR measures the strength of the desired signal relative to the background noise level; higher values indicate a cleaner signal, while lower values suggest that noise is overwhelming the signal, typically leading to increased packet loss, high latency, and reduced throughput.

Analyzing the provided graph, Carrier-1 (blue line) shows a severe drop in SNR, plummeting from approximately 4.5 dB to nearly 0.3 dB between 15:00 and 23:00. An SNR value this low is indicative of a failing or highly unstable link that cannot reliably sustain data traffic, directly supporting Inference A—that Carrier-1 experienced significant performance degradation. In contrast, Carrier-2 (green line) maintains a much higher and more consistent SNR throughout the same period.

Prisma SD-WAN’s AppFabric uses application-based path selection and SLA monitoring to ensure the best possible user experience. When the system detects that a primary path (like Carrier-1) has degraded below acceptable thresholds—often triggered by high loss or latency resulting from poor signal quality—it will dynamically steer application flows to an alternative healthy path. Therefore, Inference D is correct: because Carrier-1’s quality became untenable while Carrier-2 remained stable, the ION device would have likely initiated a path switchover to move traffic from the degraded Carrier-1 to the healthier Carrier-2.

Comprehensive and Detailed Explanation

To implement User/Group-based policies (Path, QoS, or Security) in Prisma SD-WAN, the system requires two specific components to resolve user identities and map them to IP addresses within the fabric.

Cloud Identity Engine (CIE): This is the primary requirement for identity management. The Cloud Identity Engine connects the Prisma SD-WAN controller to your directory service (e.g., Active Directory, Azure AD/Entra ID). It allows the system to retrieve and resolve User and Group attributes (e.g., "Marketing Group," "User: john.doe") so they can be selected in policy rules. Without CIE, the controller cannot interpret the group names or user identities defined in the policies.

Data Center ION: In the standard deployment model for User-ID, a Data Center (DC) ION is required to act as the bridge or collector for IP-to-User mappings. The DC ION connects to the User-ID Agent (running on a PAN-OS firewall or Windows Server) to learn the mapping of IP addresses to usernames. It then redistributes this information to the controller or other branch IONs so they can identify which user is associated with the traffic flows originating from a specific private IP address.

Comprehensive and Detailed Explanation

Prisma SD-WAN calculates the Mean Opinion Score (MOS) to provide a standardized metric (1-5) for voice quality. To ensure the system always knows the "voice readiness" of a path—even before a call starts—it uses Active Probes (synthetic UDP packets).

While latency is measured, the MOS calculation algorithm is most heavily penalized by Packet Loss (D) and Jitter (B).

Packet Loss: Even a small amount of loss (e.g., >1%) dramatically reduces voice clarity, causing dropouts.

Jitter: High variance in packet arrival time (jitter) causes the "robotic" voice effect and buffer underruns.

The system continuously measures these specific metrics on all WAN links using synthetic probes. If the packet loss or jitter exceeds the threshold defined in the "Path Quality Profile" (e.g., Voice Profile), the path is marked as non-compliant, and the MOS score drops, triggering a policy action to move the flow. Throughput (C) is less critical for voice as calls consume very little bandwidth (e.g., 64-100 Kbps), making congestion (loss/jitter) the primary enemy, not raw speed.
