The exhibit shows an aggregate route configuration for the network172.21.0.0/22, which would summarize the specific networks172.21.0.0/24,172.21.1.0/24, and172.21.2.0/24. For an aggregate route to be active, it must have contributing routes in the routing table. If the route is hidden, it usually means there are no contributing routes that are active or the policy applied to the aggregate does not match any of the specific routes.Therefore, the first step in troubleshooting would be to verify that there are indeed active contributing routes for the aggregate to be valid.

References:

• Juniper documentation on routing policies and aggregates: Junos OS Routing Policies, Firewall Filters, and Traffic Policers User Guide

When you want to advertise an interface in OSPF but not form an OSPF adjacency over that interface (for example, towards an ISP), you can configure the interface as passive. This will advertise the network on the interface in OSPF without sending OSPF hello packets or forming OSPF neighbor relationships on that interface.

References

• Juniper Networks Technical Documentation on OSPF
• OSPF Configuration Guide - Juniper Networks

To verify the status of the tunnel from R1, you would issue a ping from the source address that is assigned to R1's end of the tunnel. In the exhibit, we can see that the tunnel interface (gre-0/0/0.0) has the IP address 198.51.100.1 on R1. Therefore, to test the tunnel's status, you should ping the IP address at the other end of the tunnel (which is likely the address on User B's interface or another interface on R2) from R1's tunnel source address.

References:

• Juniper Networks documentation on GRE: GRE Interface Configuration

BGP selects the active route based on an ordered list of attributes. The correct order is:

• Weight (Cisco proprietary, not listed in the options)
• Local Preference
• Network (route) originated from the BGP router itself
• Shortest AS Path
• Lowest Origin Type
• Lowest MED
• eBGP over iBGP paths
• Closest IGP Neighbor
• Lowest Router ID

The next hop is checked for reachability but is not part of the BGP decision process for selecting the best path.

References

• Juniper Networks Technical Documentation on BGP
