CompTIA Updated 220-1101 Exam Questions and Answers by boris

The output from the cable tester indicates that there is an open fault in the cable, which means that one or more of the wires in the cable are not connected properly or are broken. The open fault affects the wires 3, 4, and 6, which are used for transmitting and receiving data in Ethernet networks. The open fault can cause network connectivity issues, such as no link, slow speed, or packet loss12.

To resolve this issue, the technician should use a crimper and a punchdown tool, which are tools that are used to attach connectors to cables or wires to patch panels. A crimper is a tool that squeezes or crimps a connector, such as an RJ-45, to the end of a cable, ensuring that the wires are securely inserted into the pins of the connector. A punchdown tool is a tool that pushes or punches a wire into a slot on a patch panel, creating a connection between the wire and the panel. Both tools can be used to fix or replace the faulty wires or connectors that cause the open fault12.

The other options are not as effective or relevant as a crimper and a punchdown tool. A loopback plug is a tool that is used to test the functionality of a network port or device, by sending and receiving signals from the same port or device. A loopback plug can help diagnose network problems, such as faulty ports or devices, but it cannot fix the open fault in the cable12. A network tap is a tool that is used to monitor or capture network traffic, by creating a copy of the data that passes through a network link. A network tap can help analyze network performance, security, or troubleshooting, but it cannot fix the open fault in the cable12. A toner probe is a tool that is used to trace or identify a cable or wire, by sending and detecting an audible tone along the cable or wire. A toner probe can help locate or label network cables or wires, but it cannot fix the open fault in the cable12. A Wi-Fi analyzer is a tool that is used to scan or measure wireless networks, by displaying information such as signal strength, channel, encryption, etc. A Wi-Fi analyzer can help optimize or troubleshoot wireless networks, but it cannot fix the open fault in the cable12.

The correct answer is D. Default gateway.

A default gateway is the device that connects a local network to other networks, such as the internet. A default gateway is usually a router or a modem that has an IP address on the same subnet as the local network. A default gateway is necessary for a device to communicate with devices outside its local network.

In this case, the user has a self-configured, static IP address of 192.168.1.20, which belongs to the subnet 192.168.1.0/24 (with a subnet mask of 255.255.255.0). However, the default gateway is set to 192.168.0.1, which belongs to a different subnet (192.168.0.0/24). This means that the user’s device cannot reach the default gateway, and therefore cannot connect to the internet.

The technician should edit the default gateway to match the correct subnet of the user’s device, such as 192.168.1.1 or 192.168.1.254, depending on the configuration of the network.

The problem in this scenario is that the battery charger is not a USB device, but a device that plugs into a USB port to draw power. Therefore, it does not have a unique identifier that can be recognized by the peripheral security software, which is designed to prevent unauthorized USB devices from accessing the company’s network or data. The security software cannot add the battery charger to its whitelist, and may block its power supply or generate alerts.

The best solution for this problem is to provide a USB to AC adapter for the battery charger, which is a device that converts the USB power output to an AC power input that can be plugged into a wall outlet. This way, the battery charger does not need to connect to the docking station or the computer, and does not trigger the peripheral security software. The user can still charge the camera’s battery without compromising the company’s security policy.

The other options are not advisable because they either do not solve the problem or create new risks. Option B, adding a powered USB hub to the docking station, may not work if the security software also monitors the hub’s ports and detects the battery charger as an unknown device. Option C, disabling the peripheral security software for this user only, is a very bad idea because it exposes the user’s computer and the company’s network to potential attacks from malicious USB devices. Option D, replacing the battery charger with a USB device that has a unique identifier, is unnecessary and costly, and may not be compatible with the camera’s battery.

The most likely cause of the issue is C. Physical cabling issues.

Physical cabling issues can affect the quality and stability of the display signal. If the cable is loose, damaged, or bent, it may cause intermittent connection, interference, or signal loss. This can result in slow, distorted, discolored, or blank display.

To troubleshoot physical cabling issues, the user should check the following steps:

•Make sure the cable is firmly connected to both the display and the video adapter.

•Inspect the cable for any signs of damage, such as cuts, frays, kinks, or exposed wires.

•Check the cable connectors for any bent or broken pins.

•Try a different cable or a different port on the display or the video adapter.

•If possible, test the display with another device or test another display with the same device.

The other options are less likely to cause the issue, because:

•Incorrect data source may result in no display or an error message, but not slow or distorted display.

•Incorrect resolution settings may cause stretched, blurry, or cropped display, but not discolored or blank display.

•Incorrect refresh rate may cause flickering or tearing display, but not slow or distorted display.

•Display burn-in may cause permanent image retention or ghosting on the display, but not intermittent or blank display.
