CompTIA Updated 220-1101 Exam Questions and Answers by nella

The disk failure notice during startup indicates that one or more disks in the RAID array have failed. The machine still seems to startup into Windows but at a much slower speed because the RAID 5 configuration can tolerate one disk failure and still operate, but with reduced performance and reliability. The technician most likely needs to rebuild the RAID, which means replacing the failed disk(s) and restoring the data from the parity information. Reinstalling the HDD drivers will not fix the disk failure. Replacing the failed drivers is not a valid option, as drivers are software, not hardware. Restarting the system will not fix the disk failure either. References: https://www.comptia.org/blog/what-is-raid-0-1-5-6-10

The technician should ensure that a VGA cable is connected properly between the monitor and the computer. A VGA cable is a type of video cable that carries analog signals. If the cable is loose, damaged, or not plugged in correctly, it can cause the monitor to not display any image or show distorted colors. According to the CompTIA Core1 objectives, one of the common display issues is no image on screen. A troubleshooting guide for monitors also recommends checking the VGA cable connection as a possible solution for no signal or blank screen problems.

Memory modules are physical components that store data and instructions for the computer to access and process. Memory modules have different specifications and features, such as type, speed, capacity, voltage, and form factor. These specifications and features must be compatible with the motherboard and the processor of the computer, otherwise the memory modules may not work properly or cause errors.

In this scenario, the technician is working to replace a single DDR3 RAM module on a laptop that has two occupied slots. DDR3 stands for Double Data Rate 3, and it is a type of memory technology that offers faster performance and lower power consumption than its predecessors. DDR3 RAM modules have different variants, such as DDR3L, DDR3U, or DDR3R, which have different voltage requirements. For example, DDR3L operates at 1.35V, DDR3U operates at 1.25V, and DDR3R operates at 1.5V.

When the technician tries to turn on the laptop, the computer starts beeping and does not pass POST. POST stands for Power-On Self-Test, and it is a process that checks the hardware components and functionality of the computer before loading the operating system. If POST detects an error or a failure, it may produce a series of beeps or codes to indicate the problem. The number and pattern of beeps or codes may vary depending on the manufacturer or model of the computer.

The technician double-checks the newly installed RAM and notices a motherboard message indicating low voltage. This means that the motherboard is not receiving enough power from the memory module to operate normally. This could indicate that the memory module is not compatible with the motherboard or the processor, or that it is defective or damaged. The most likely cause of this issue is that the technician installed an unsupported memory module that has a lower voltage than what the motherboard or the processor requires.

To resolve this issue, the technician should remove the newly installed RAM module and replace it with a compatible one that has the same voltage as the existing ones. The technician should also check the specifications and features of the motherboard and the processor to ensure that they support the type, speed, capacity, and form factor of the memory modules. The technician should also follow proper safety precautions when handling memory modules, such as wearing an anti-static wrist strap, avoiding physical damage or static discharge, and aligning the notches correctly.

The manufacturer’s specifications for the components are the best source of information to determine the appropriate power supply for the workstation. The manufacturer’s specifications will list the power requirements and recommendations for each component, such as the graphics card, the CPU, the hard drives, and the motherboard. By adding up the power consumption of each component, the technician can estimate the total wattage needed for the workstation. The technician should also consider some extra headroom for future upgrades or peak loads. The technician can then choose a power supply that meets or exceeds the total wattage and has the right connectors and form factor for the workstation.
