CompTIA Updated 220-1101 Exam Questions and Answers by malaika

DHCP stands for Dynamic Host Configuration Protocol, which is a protocol that provides quick, automatic, and central management for the distribution of IP addresses within a network1. A DHCP server can assign IP addresses and other network information to devices that request them, such as computers, smartphones, and routers2.

The IP address 169.254.2.2 is an example of an APIPA (Automatic Private IP Addressing) address, which is a special type of IP address that devices use when they cannot obtain a valid IP address from a DHCP server3. APIPA addresses are in the range of 169.254.0.1 to 169.254.255.254, with a subnet mask of 255.255.0.03. Devices that use APIPA addresses can only communicate with other devices on the same local network that also use APIPA addresses3.

The router in the question is assigned the address scope of 192.168.1.254/24, which means it has an IP address of 192.168.1.254 and a subnet mask of 255.255.255.04. This address scope belongs to the private IP address range of 192.168.0.0 to 192.168.255.255, which is commonly used for local networks4. Devices that use private IP addresses can communicate with other devices on the same local network or across different networks through NAT (Network Address Translation)4.

The most likely cause of the technician receiving the IP address 169.254.2.2 is that the DHCP server on the router is not working properly or is not configured correctly3. This could be due to various reasons, such as a misconfigured router, a faulty cable, a firewall blocking DHCP traffic, or an exhausted pool of IP addresses3. As a result, the technician’s device cannot obtain a valid IP address from the DHCP server and resorts to using an APIPA address instead3.

To fix this issue, the technician should check the router settings and make sure that the DHCP server is enabled and has enough available IP addresses to assign to devices2. The technician should also check the physical cabling and make sure it is properly connected and secured2. If the issue persists, the technician should try rebooting the router or resetting it to factory defaults2. Alternatively, the technician could manually assign a static IP address to the device that matches the router’s address scope, such as 192.168.1.x/242.

The correct answer is C. Ethernet.

An Ethernet cable is a type of network cable that is used to connect devices on a local area network (LAN), such as computers, routers, switches, and modems. Ethernet cables have RJ-45 connectors at both ends, which are similar to telephone jacks but larger. Ethernet cables can carry data signals at speeds ranging from 10 Mbps to 10 Gbps, depending on the type and quality of the cable.

A cable modem is a device that connects to a coaxial cable from a cable service provider and provides high-speed internet access. A SOHO router is a small office/home office router that connects to a cable modem or DSL modem and provides network and internet access to multiple devices on a LAN. A SOHO router typically has one WAN port and four LAN ports. The WAN port is used to connect to the cable modem or DSL modem, while the LAN ports are used to connect to computers or other devices on the LAN.

To connect a cable modem to a SOHO router, an Ethernet cable is needed. The Ethernet cable is plugged into the WAN port of the SOHO router and the Ethernet port of the cable modem. This allows the SOHO router to receive an IP address from the cable service provider and share it with the devices on the LAN using network address translation (NAT). The SOHO router also provides firewall and wireless features for the LAN.

The other options are incorrect because they are not suitable for connecting a cable modem to a SOHO router. FireWire is a type of serial bus that is used to connect devices such as digital cameras, external hard drives, and audio interfaces. FireWire cables have different connectors than Ethernet cables and cannot be used for network communication. Fiber is a type of optical cable that uses light signals to transmit data over long distances. Fiber cables have special connectors that are not compatible with Ethernet ports. Coaxial is a type of copper cable that has a central conductor surrounded by an insulating layer and a braided shield. Coaxial cables are used for cable TV and internet services, but they cannot be directly connected to Ethernet ports without an adapter.

References:

CompTIA A+ Certification Exam: Core 1 Objectives (220-1001)

Installing and Configuring a Cable Modem/DSL Router

Cisco 831 Router and SOHO 91 Router Cabling and Setup Quick Start Guide

A hotspot is a feature that allows a phone to share its cellular data connection with other devices via Wi-Fi, Bluetooth, or USB. This can be useful when traveling on a train, where Wi-Fi networks may not be available or reliable. A hotspot can provide internet access to a laptop or other devices that need to connect to the web.

Bluetooth is a wireless technology that allows devices to communicate over short distances, usually within 10 meters. It can be used to pair devices such as headphones, speakers, keyboards, mice, etc. However, it cannot be used to share internet access from a phone to a laptop.

Near-field communication (NFC) is a wireless technology that allows devices to exchange data by touching or bringing them close together, usually within 4 cm. It can be used for applications such as contactless payments, smart cards, digital tickets, etc. However, it cannot be used to share internet access from a phone to a laptop.

Roaming is a feature that allows a phone to use another carrier’s network when the home network is not available. This can be useful when traveling abroad, where the home network may not have coverage or agreements with local operators. However, roaming can incur additional charges and may not provide the same speed or quality of service as the home network. Roaming does not affect the ability of the phone to share internet access with other devices via hotspot.
